CO2 Welding Wire

NK-59


CLASSIFICATION

AWS A5.18 ER70S-6 ; JIS Z 3312 YGW12

PRODUCT DESCRIPTION

For welding mild steel and 50 kg/mm2 class high tensile steel

WELDING FEATURES OF THE ELECTRODE

NK-58 is a solid wire which has been designed to get good usability and are intended for both single and multipass welding. Copper coating ensures problem free wire feeding, smooth current pick-up and minimal contant tip wire. They are especially suited for sheet metal applications, where smooth weld beads are desired and structural and plate steels with high deposition recovery up to 95%.

APPLICATIONS AND MATERIALS TO BE WELDED

For butt and fillet welding of structural steels, and general fabrication such as pressure vessel plates, carbon steel, for intermediate and higher temperature service, or for moderate and lower temperature service.

WELDING AMPERAGE AC and DC

RECOMMENDED CURRENTS: DCEP

Diameter (mm)

0.8

1.0

1.2

Current Range (Amp.)

60 ~ 150

80 ~ 250

100 ~ 350

Voltage Range (Volt)

18 ~ 24

18 ~ 32

18 ~ 34

OTHER DATA

PACKAGE

Diameter (mm)

Weight in drums (kgs)

0.8 ; 1.0 ; 1.2

250
